X3120 III KV760 BRUSHLESS MOTOR
0 Puan - 0 Yorum
4.140,00 TL
Stator Çapı 31mm
Rotor Çapı 37.7mm
Stator Kalınlığı 20mm
Gövde Uzunluğu 42mm
Stator Yuvası Sayısı 12
Maksimum Lipo Hücresi 3-5S
Rotor Kutup Sayısı 14
ESC 60-80A
Motor Kv 760
Önerilen Prop(inç) 4-5S(APC12*8/APC12*6) 4S(APC13*6.5/APC13*8) 3S(APC14*7)
Yüksüz akım 1.3A/10V
Akrobasi uçağı için ağırlık 1400g-1800g (4-5S APC12*6\APC12*8) (4S APC13*6.5\APC13*8)
Motor Direnci 27.5mΩ
3D uçak için ağırlık 1100g-1400g (4S APC12*6\APC12*8\APC13*6.5\APC13*8)
Maksimum Sürekli Akım 65A/30s
Maksimum Sürekli Güç 1000W
Ağırlık 157g
| Prop(inch) | Voltage(V) | Amps(A) | Thrust(gf) | Watts(W) | Efficiency(g/W) | RPM | Load temperature in 100% throttle |
|---|---|---|---|---|---|---|---|
| APC12*8 | 14.8 | 4.1 | 500 | 60.68 | 8.24 | 4210 | 125℃ 2min |
| 7 | 750 | 103.6 | 7.24 | 5176 | |||
| 10.5 | 1000 | 155.4 | 6.44 | 5918 | |||
| 14.4 | 1250 | 213.12 | 5.87 | 6520 | |||
| 18.7 | 1500 | 276.76 | 5.42 | 7117 | |||
| 23.5 | 1750 | 347.8 | 5.03 | 7690 | |||
| 28.7 | 2000 | 424.76 | 4.71 | 8220 | |||
| 35.6 | 2250 | 526.88 | 4.27 | 8890 | |||
| 41.5 | 2310 | 614.2 | 3.76 | 8968 | |||
| 16.8 | 3.6 | 500 | 60.48 | 8.27 | 4206 | ||
| 6.2 | 750 | 104.16 | 7.20 | 5178 | |||
| 9.2 | 1000 | 154.56 | 6.47 | 5918 | |||
| 12.8 | 1250 | 215.04 | 5.81 | 6541 | |||
| 16.5 | 1500 | 277.2 | 5.41 | 7117 | |||
| 20.6 | 1750 | 346.08 | 5.06 | 7680 | |||
| 25.5 | 2000 | 428.4 | 4.67 | 8290 | |||
| 30.7 | 2250 | 515.76 | 4.36 | 8896 | |||
| 53.3 | 2840 | 895.44 | 3.17 | 9639 | |||
| 18.5 | 3.2 | 500 | 59.2 | 8.45 | 4210 | ||
| 5.8 | 750 | 107.3 | 6.99 | 5180 | |||
| 8.5 | 1000 | 157.25 | 6.36 | 5920 | |||
| 11.7 | 1250 | 216.45 | 5.78 | 6520 | |||
| 15.3 | 1500 | 283.05 | 5.30 | 7111 | |||
| 19 | 1750 | 351.5 | 4.98 | 7690 | |||
| 23.7 | 2000 | 438.45 | 4.56 | 8218 | |||
| 28.2 | 2250 | 521.7 | 4.31 | 8890 | |||
| 34.3 | 2500 | 634.55 | 3.94 | 9334 | |||
| 63.5 | 3220 | 1174.75 | 2.74 | 10200 | |||
| APC12*6 | 14.8 | 3.9 | 500 | 57.72 | 8.66 | 4650 | 123℃ 2min |
| 6.6 | 750 | 97.68 | 7.68 | 5655 | |||
| 9.9 | 1000 | 146.52 | 6.83 | 6499 | |||
| 13.1 | 1250 | 193.88 | 6.45 | 7160 | |||
| 17.2 | 1500 | 254.56 | 5.89 | 7780 | |||
| 21.8 | 1750 | 322.64 | 5.42 | 8275 | |||
| 26.7 | 2000 | 395.16 | 5.06 | 8820 | |||
| 38.8 | 2530 | 574.24 | 4.41 | 9409 | |||
| 16.8 | 3.5 | 500 | 58.8 | 8.50 | 4652 | ||
| 5.9 | 750 | 99.12 | 7.57 | 5680 | |||
| 8.7 | 1000 | 146.16 | 6.84 | 6450 | |||
| 11.8 | 1250 | 198.24 | 6.31 | 7200 | |||
| 15.4 | 1500 | 258.72 | 5.80 | 7790 | |||
| 19.1 | 1750 | 320.88 | 5.45 | 8225 | |||
| 23.8 | 2000 | 399.84 | 5.00 | 8865 | |||
| 28.5 | 2250 | 478.8 | 4.70 | 9218 | |||
| 34 | 2500 | 571.2 | 4.38 | 9689 | |||
| 46.6 | 3020 | 782.88 | 3.86 | 10169 | |||
| 18.5 | 3.2 | 500 | 59.2 | 8.45 | 4560 | ||
| 5.4 | 750 | 99.9 | 7.51 | 5700 | |||
| 8 | 1000 | 148 | 6.76 | 6450 | |||
| 10.8 | 1250 | 199.8 | 6.26 | 7182 | |||
| 14.1 | 1500 | 260.85 | 5.75 | 7790 | |||
| 17.5 | 1750 | 323.75 | 5.41 | 82225 | |||
| 21.8 | 2000 | 403.3 | 4.96 | 8863 | |||
| 26 | 2250 | 481 | 4.68 | 9370 | |||
| 31.3 | 2500 | 579.05 | 4.32 | 9660 | |||
| 55 | 3450 | 1017.5 | 3.39 | 10980 | |||
| 21 | 2.8 | 500 | 58.8 | 8.50 | 4650 | ||
| 4.8 | 750 | 100.8 | 7.44 | 5680 | |||
| 7.1 | 1000 | 149.1 | 6.71 | 6459 | |||
| 9.8 | 1250 | 205.8 | 6.07 | 7128 | |||
| 12.6 | 1500 | 264.6 | 5.67 | 7760 | |||
| 15.8 | 1750 | 331.8 | 5.27 | 8222 | |||
| 19.6 | 2000 | 411.6 | 4.86 | 8685 | |||
| 21.15 | 2250 | 444.15 | 5.07 | 9204 | |||
| 27.9 | 2500 | 585.9 | 4.27 | 9640 | |||
| 33 | 2750 | 693 | 3.97 | 10042 | |||
| 38.8 | 3000 | 814.8 | 3.68 | 10529 | |||
| 65.2 | 3940 | 1369.2 | 2.88 | 11938 | |||
| APC13*6.5 | 14.8 | 3.5 | 500 | 51.8 | 9.65 | 3990 | 90℃ 3min |
| 6.5 | 750 | 96.2 | 7.80 | 4721 | |||
| 9.3 | 1000 | 137.64 | 7.27 | 5501 | |||
| 12.6 | 1250 | 186.48 | 6.70 | 6110 | |||
| 16.3 | 1500 | 241.24 | 6.22 | 6567 | |||
| 20.9 | 1750 | 309.32 | 5.66 | 7067 | |||
| 25.8 | 2000 | 381.84 | 5.24 | 7510 | |||
| 30.5 | 2250 | 451.4 | 4.98 | 7932 | |||
| 36.4 | 2500 | 538.72 | 4.64 | 8324 | |||
| 47.6 | 2960 | 704.48 | 4.20 | 8992 | |||
| 16.8 | 3.2 | 500 | 53.76 | 9.30 | 3965 | ||
| 5.6 | 750 | 94.08 | 7.97 | 4701 | |||
| 8.3 | 1000 | 139.44 | 7.17 | 5521 | |||
| 11.2 | 1250 | 188.16 | 6.64 | 6130 | |||
| 14.9 | 1500 | 250.32 | 5.99 | 6587 | |||
| 18.1 | 1750 | 304.08 | 5.76 | 7047 | |||
| 23 | 2000 | 386.4 | 5.18 | 7502 | |||
| 27.4 | 2250 | 460.32 | 4.89 | 7922 | |||
| 32.6 | 2500 | 547.68 | 4.56 | 8230 | |||
| 38.1 | 2750 | 640.08 | 4.30 | 8604 | |||
| 44.8 | 3000 | 752.64 | 3.99 | 9010 | |||
| 55.6 | 3540 | 934.08 | 3.79 | 9498 | |||
| APC13*8 | 14.8 | 3.6 | 500 | 53.28 | 9.38 | 3777 | 110℃ 4min |
| 6.2 | 750 | 91.76 | 8.17 | 4555 | |||
| 9.6 | 1000 | 142.08 | 7.04 | 5200 | |||
| 13 | 1250 | 192.4 | 6.50 | 5789 | |||
| 17.2 | 1500 | 254.56 | 5.89 | 6258 | |||
| 21.1 | 1750 | 312.28 | 5.60 | 6670 | |||
| 26.9 | 2000 | 398.12 | 5.02 | 7181 | |||
| 31.9 | 2250 | 472.12 | 4.77 | 7575 | |||
| 38.6 | 2500 | 571.28 | 4.38 | 8013 | |||
| 49.8 | 2930 | 737.04 | 3.98 | 8600 | |||
| 16.8 | 3.3 | 500 | 55.44 | 9.02 | 3750 | ||
| 5.7 | 750 | 95.76 | 7.83 | 4535 | |||
| 8.6 | 1000 | 144.48 | 6.92 | 5189 | |||
| 11.7 | 1250 | 196.56 | 6.36 | 5777 | |||
| 15.5 | 1500 | 260.4 | 5.76 | 6256 | |||
| 19.3 | 1750 | 324.24 | 5.40 | 6890 | |||
| 23.7 | 2000 | 398.16 | 5.02 | 7333 | |||
| 28.8 | 2250 | 483.84 | 4.65 | 7769 | |||
| 33.9 | 2500 | 569.52 | 4.39 | 8000 | |||
| 40.5 | 2750 | 680.4 | 4.04 | 8355 | |||
| 47.1 | 3000 | 791.28 | 3.79 | 8800 | |||
| 61 | 3520 | 1024.8 | 3.43 | 9280 | |||
| APC14*7 | 14.8 | 3.4 | 500 | 50.32 | 9.94 | 3360 | 127℃ 2min |
| 5.9 | 750 | 87.32 | 8.59 | 4089 | |||
| 8.9 | 1000 | 131.72 | 7.59 | 4675 | |||
| 12.1 | 1250 | 179.08 | 6.98 | 5260 | |||
| 15.6 | 1500 | 230.88 | 6.50 | 5620 | |||
| 19.6 | 1750 | 290.08 | 6.03 | 6060 | |||
| 24.5 | 2000 | 362.6 | 5.52 | 6506 | |||
| 29.6 | 2250 | 438.08 | 5.14 | 6870 | |||
| 35.5 | 2500 | 525.4 | 4.76 | 7219 | |||
| 41.7 | 2750 | 617.16 | 4.46 | 7490 | |||
| 51.2 | 3350 | 757.76 | 4.42 | 8117 | |||
| 16.8 | 2.8 | 500 | 47.04 | 10.63 | 3340 | ||
| 5.2 | 750 | 87.36 | 8.59 | 4087 | |||
| 7.9 | 1000 | 132.72 | 7.53 | 4672 | |||
| 10.9 | 1250 | 183.12 | 6.83 | 5235 | |||
| 13.8 | 1500 | 231.84 | 6.47 | 5620 | |||
| 17.6 | 1750 | 295.68 | 5.92 | 6060 | |||
| 21.8 | 2000 | 366.24 | 5.46 | 6506 | |||
| 26.4 | 2250 | 443.52 | 5.07 | 6800 | |||
| 31.9 | 2500 | 535.92 | 4.66 | 7217 | |||
| 37.2 | 2750 | 624.96 | 4.40 | 7520 | |||
| 43.9 | 3000 | 737.52 | 4.07 | 7789 | |||
| 59.2 | 3500 | 994.56 | 3.52 | 8338 | |||
| 67 | 3819 | 1125.6 | 3.39 | 8699 |
